ARPA molding lines with PLC control
Flask less size 508 X 508 X 200
Flask Box size 711 X 635 X 250
Producing Grey Cast Iron and ductile Iron casting
3D inspection of casting by GOM ATOS COMPACT SCAN 2M scanner, Germany
Sand cooler from Sinpson (Control on Moisture and Temperature)
Critical core setting using Pneumatic core setting fixtures
Floor Shop Covering 34000 Sq. Feet
Office Area Covering 6000 Sq. Feet
Environment & Eco-Friendly
Rain Water Harvesting System catering 35,000 liter/hour
Robotic Pick & Place Line for mass production
Well Equipped Metrology Lab with world class equipment, world class machine tools with combination of 2 Axis, 3 Axis, 4 Axis and latest 5 Axis Machines.
Centralized Coolant System for effective coolant management.
Installed 2000 MT/Month capacity of Grey Iron Casting.
Commencement of Production from October 2020.
High Pressure Flask less molding line from DISA.
Flask Size: 610 x 710 x 254 (cope) + 254 (drag).
Auto Pouring System.
3D inspection of casting by GOM ATOS COMPACT SCAN 2M scanner, Germany.
Robotic fettling and core handling will be started in Second phase March 2021.
Rain Water Harvesting System catering 100,000 Liters/Hour.
Total Land : 3,74,000 Sq. Ft. (8.5 Acre).
Built-up Area : 62,000 Sq. Ft.
